Dane techniczne
| Symbol | Przył. G |
Śred. nom. |
Wsp. Przep. CV |
Min. ciś. różn |
Max. ciś. różn. pracy | Max. temp. |
||||||
| Powietrze gazy |
Woda płyny |
Olej lekki <20cSt |
||||||||||
| AC | DC | AC | DC | AC | DC | |||||||
| mosiądz | AISI 316/304 | cal | mm | – | bar | bar | bar | bar | bar | bar | bar | °C |
| EZ-10-E2-16L-H | EZ-10-E2-16LS2-H | 3/8″ | 16 | 4,8 | 0 | 5 | 3 | 5 | 3 | 3 | 3 | 80 |
| EZ-10-EE2-16L-H | EZ-10-EE2-16LS2-H | 3/8″ | 16 | 4,8 | 0 | 5 | 3 | 5 | 3 | – | – | 120 |
| EZ-10-VE2-16L-H | EZ-10-VE2-16LS2-H | 3/8″ | 16 | 4,8 | 0 | 5 | 3 | 5 | 3 | 3 | 3 | 120 |
| EZ-15-E2-16L-H | EZ-15-E2-16LS2-H | 1/2″ | 16 | 4,8 | 0 | 5 | 3 | 5 | 3 | 3 | 3 | 80 |
| EZ-15-EE2-16L-H | EZ-15-EE2-16LS2-H | 1/2″ | 16 | 4,8 | 0 | 5 | 3 | 5 | 3 | – | – | 120 |
| EZ-15-VE2-16L-H | EZ-15-VE2-16LS2-H | 1/2″ | 16 | 4,8 | 0 | 5 | 3 | 5 | 3 | 3 | 3 | 120 |
| EZ-20-E2-H | EZ-20-E2S2-H | 3/4″ | 20 | 7,6 | 0 | 5 | 3 | 5 | 3 | 3 | 3 | 80 |
| EZ-20-EE2-H | EZ-20-EE2S2-H | 3/4″ | 20 | 7,6 | 0 | 5 | 3 | 5 | 3 | – | – | 120 |
| EZ-20-VE2-H | EZ-20-VE2S2-H | 3/4″ | 20 | 7,6 | 0 | 5 | 3 | 5 | 3 | 3 | 3 | 120 |
| EZ-25-E2-H | EZ-25-E2S2-H | 1″ | 25 | 12 | 0 | 5 | 3 | 5 | 3 | 3 | 3 | 80 |
| EZ-25-EE2-H | EZ-25-EE2S2-H | 1″ | 25 | 12 | 0 | 5 | 3 | 5 | 3 | – | – | 120 |
| EZ-25-VE2-H | EZ-25-VE2S2-H | 1″ | 25 | 12 | 0 | 5 | 3 | 5 | 3 | 3 | 3 | 120 |
| EZ-35-E2-H | EZ-35-E2S2-H | 1-1/4″ | 32 | 24 | 0 | 5 | 3 | 5 | 3 | 3 | 3 | 80 |
| EZ-35-EE2-H | EZ-35-EE2S2-H | 1-1/4″ | 32 | 24 | 0 | 5 | 3 | 5 | 3 | – | – | 120 |
| EZ-35-VE2-H | EZ-35-VE2S2-H | 1-1/4″ | 32 | 24 | 0 | 5 | 3 | 5 | 3 | 3 | 3 | 120 |
| EZ-40-E2-H | EZ-40-E2S2-H | 1-1/2″ | 40 | 29 | 0 | 5 | 3 | 5 | 3 | 3 | 3 | 80 |
| EZ-40-EE2-H | EZ-40-EE2S2-H | 1-1/2″ | 40 | 29 | 0 | 5 | 3 | 5 | 3 | – | – | 120 |
| EZ-40-VE2-H | EZ-40-VE2S2-H | 1-1/2″ | 40 | 29 | 0 | 5 | 3 | 5 | 3 | 3 | 3 | 120 |
| EZ-50-E2-H | EZ-50-E2S2-H | 2″ | 50 | 48 | 0 | 5 | 3 | 5 | 3 | 3 | 3 | 80 |
| EZ-50-EE2-H | EZ-50-EE2S2-H | 2″ | 50 | 48 | 0 | 5 | 3 | 5 | 3 | – | – | 120 |
| EZ-50-VE2-H | EZ-50-VE2S2-H | 2″ | 50 | 48 | 0 | 5 | 3 | 5 | 3 | 3 | 3 | 120 |
